Chapter 41 Configuring PFC QoS
Configuring PFC QoS
To configure the drop thresholds, perform this task:
This example shows how to configure the receive-queue drop thresholds for Gigabit Ethernet port 1/1:
Router# configure terminal
Enter configuration commands, one per line. End with CNTL/Z.
Router(config)# interface gigabitethernet 1/1
Router(config-if)# rcv-queue threshold 1 60 75 85 100
Router(config-if)# end
Router#
This example shows how to verify the configuration:
Router# show queueing interface gigabitethernet 1/1 | begin Receive queues
Receive queues [type = 1p1q4t]:
Queue Id Scheduling Num of thresholds
-----------------------------------------
1 Standard 4
2 Priority 1
Trust state: trust COS
queue tail-drop-thresholds
--------------------------
1 60[1] 75[2] 85[3] 100[4]
<...Output Truncated...>
Router#
Configuring a WRED-Drop Transmit Queue
These port types have only WRED-drop thresholds in their transmit queues:
• 1p2q2t (transmit)
• 1p2q1t (transmit)
Command Purpose
Step 1
Router(config)# interface {fastethernet |
gigabitethernet}
slot/port
Selects the interface to configure.
Step 2
Router(config-if)# rcv-queue threshold
queue_id
thr1% thr2% thr3% thr4%
{
thr5% thr6% thr7% thr8%
}
Configures the receive-queue tail-drop threshold
percentages.
Router(config-if)# no rcv-queue threshold
[
queue_id
]
Reverts to the default receive-queue tail-drop threshold
percentages.
Step 3
Router(config-if)# end
Exits configuration mode.
Step 4
Router# show queueing interface {fastethernet |
gigabitethernet}
slot/port
Verifies the configuration.
Command Purpose
Step 1
Router(config)# interface type
1
slot/port
Selects the interface to configure.
Step 2
Router(config-if)# wrr-queue random-detect
min-threshold
queue_id thr1%
[
thr2%
]
Configures the low WRED-drop thresholds.
Router(config-if)# no wrr-queue random-detect
min-threshold [
queue_id
]
Reverts to the default low WRED-drop thresholds.
