41-104
Cisco 7600 Series Router Cisco IOS Software Configuration Guide, Release 12.2SX
OL-4266-08
Chapter 41 Configuring PFC QoS
Configuring PFC QoS
Note The eighth queue is the strict priority queue in the output of the show queueing interface command.
This example shows how to verify the configuration:
Router# show queueing interface tengigabitethernet 6/1 | begin queue thresh dscp-map
queue thresh dscp-map
---------------------------------------
1 1 0 1 2 3 4 5 6 7 8 9 11 13 15 16 17 19 21 23 25 27 29 31 33 39 41 42 43 44 45 47
1 2
1 3
1 4
2 1 14
2 2 12
2 3 10
2 4
3 1 22
3 2 20
3 3 18
3 4
4 1 24 30
4 2 28
4 3 26
4 4
5 1 32 34 35 36 37 38
5 2
5 3
5 4
6 1 48 49 50 51 52 53 54 55 56 57 58 59 60 61 62 63
6 2
6 3
6 4
7 1
7 2
7 3
7 4
8 1 40 46
<...Output Truncated...>
Router#
Mapping DSCP Values to the Transmit Strict-Priority Queue
To map DSCP values to the transmit strict-priority queue, perform this task:
Command Purpose
Step 1
Router(config)# interface tengigabitethernet
slot/port
Selects the interface to configure.
Step 2
Router(config-if)# priority-queue dscp-map
queue_# dscp1 [ dscp2 [ dscp3 [ dscp4 [ dscp5 [ dscp6
[
dscp7 [ dscp8 ]]]]]]]
Maps DSCP values to the transmit strict-priority queue.
You can enter multiple priority-queue dscp-map
commands to map more than 8 DSCP values to the
strict-priority queue.
Router(config-if)# no priority-queue dscp-map
Reverts to the default mapping.
Step 3
Router(config-if)# end
Exits configuration mode.
Step 4
Router# show queueing interface
tengigabitethernet
slot/port
Verifies the configuration.
