43-5
Cisco 7600 Series Router Cisco IOS Software Configuration Guide, Release 12.2SX
OL-4266-08
Chapter 43 Configuring PFC QoS Statistics Data Export
Configuring PFC QoS Statistics Data Export
Enabling PFC QoS Statistics Data Export for a Class Map
To enable PFC QoS statistics data export for a class map, perform this task:
This example shows how to enable PFC QoS statistics data export for a class map named class3 and
verify the configuration:
Router# configure terminal
Router(config)# mls qos statistics-export class-map class3
Router(config)# end
Router# show mls qos statistics-export info
QoS Statistics Data Export Status and Configuration information
---------------------------------------------------------------
Export Status : enabled
Export Interval : 300 seconds
Export Delimiter : |
Export Destination : Not configured
QoS Statistics Data Export is enabled on following ports:
---------------------------------------------------------
FastEthernet5/24
QoS Statistics Data export is enabled on following shared aggregate policers:
-----------------------------------------------------------------------------
aggr1M
QoS Statistics Data Export is enabled on following class-maps:
---------------------------------------------------------------
class3
Router#
When enabled for a class map, PFC QoS statistics data export contains the following fields, separated
by the delimiter character:
• For data from a physical port:
–
Export type (“4” for a classmap and port)
–
Class map name
–
Direction (“in”)
–
Slot/port
–
Number of in-profile bytes
–
Number of bytes that exceed the CIR
–
Number of bytes that exceed the PIR
–
Time stamp
Command Purpose
Step 1
Router(config)# mls qos statistics-export
class-map
classmap_name
Enables PFC QoS statistics data export for a class map.
Router(config)# no mls qos statistics-export
class-map
classmap_name
Disables PFC QoS statistics data export for a class map.
Step 2
Router(config)# end
Exits configuration mode.
Step 3
Router# show mls qos statistics-export info
Verifies the configuration.
