Appendix A Online Diagnostic Tests
Global Health-Monitoring Tests
• IPSEC Services Modules Tests, page A-32
• Stress Tests, page A-33
• Critical Recovery Tests, page A-34
• General Tests, page A-36
Tip For additional information (including configuration examples and troubleshooting information), see the
documents listed on this page:
http://www.cisco.com/en/US/products/hw/routers/ps368/tsd_products_support_series_home.html
Global Health-Monitoring Tests
The global health monitoring tests consist of the following tests:
TestSPRPInbandPing, page A-2
TestMacNotification, page A-3
TestSPRPInbandPing
The TestSPRPIinbandPing test detects most runtime software driver and hardware problems on
supervisor engines by running diagnostic packet tests using the Layer 2 forwarding engine, the Layer 3
and 4 forwarding engine, and the replication engine on the path from the switch processor to the route
processor. Packets are sent at 15-second intervals. Ten consecutive failures of the test results in failover
to the redundant supervisor engine (default) or reload of the supervisor engine if a redundant supervisor
engine is not installed.
TestScratchRegister
The TestScratchRegister test monitors the health of application-specific integrated circuits (ASICs) by
writing values into registers and reading back the values from these registers. The test runs every 30
seconds. Five consecutive failures causes a supervisor engine to switchover (or reset), if you are testing
the supervisor engine, or in the module powering down when testing a module.
Ta b l e A-1 TestSPRPInbandPing Test Attributes
Attribute Description
Disruptive/Nondisruptive Nondisruptive.
Recommendation
Do not disable. Test is automatically disabled during
CPU-usage spikes in order to maintain accuracy.
Default On.
Release 12.1(13)E, 12.2(14)SX to12.2(17d)SXB5, and 12.2(18)SXD.
Corrective action Reset the active supervisor engine.
Hardware support Active and standby supervisor engine.
