A-8
Cisco 7600 Series Router Cisco IOS Software Configuration Guide, Release 12.2SX
OL-4266-08
Appendix A Online Diagnostic Tests
PFC Layer 2 Forwarding Engine Tests
TestBadBpduTrap
The TestBadBpduTrap test is a combination of the TestTrap and the TestBadBpdu tests, which are
described in the
“DFC Layer 2 Forwarding Engine Tests” section on page A-9.
TestMatchCapture
The TestMatchCapture test is a combination of the TestProtocolMatchChannel and the TestCapture tests,
which are described in the
“DFC Layer 2 Forwarding Engine Tests” section on page A-9.
Corrective action None. See the system message guide for more information.
Hardware support Supervisor engines only.
Table A-10 TestDontConditionalLearn Test Attributes (continued)
Ta b l e A-11 TestBadBpduTrap Test Attributes
Attribute Description
Disruptive/Nondisruptive Disruptive.
Recommendation
If you experience problems with the Layer 2 forwarding
engine learning capability, run this test on-demand to verify
the Layer 2 learning functionality. This test can also be used
as a health-monitoring test.
Default This test runs by default during bootup or after a reset or OIR.
Release 12.1(13)E, 12.2(14)SX.
Corrective action None. See the system message guide for more information.
Hardware support Supervisor engines only.
Ta b l e A-12 TestMatchCapture Test Attributes
Attribute Description
Disruptive/Nondisruptive Disruptive.
Recommendation
If you experience problems with the Layer 2 forwarding
engine learning capability, run this test on-demand to verify
the Layer 2 learning functionality. This test can also be used
as a health-monitoring test.
Default This test runs by default during bootup or after a reset or OIR.
Release 12.1(13)E, 12.2(14)SX.
Corrective action None. See the system message guide for more information.
Hardware support Supervisor engines only.
