3-8
Cisco Integrated Services Router Hardware Installation Guide
Chapter 3 Connecting the Router
Cisco 860, 880, 890 Series
Cisco 860, 880, 890 Series
This section describes how to connect Cisco 860 series, Cisco 880 series, and Cisco 890 series ISRs to
Ethernet devices, Power over Ethernet (PoE), and a network.
Note Depending on the features available for your router, some content in this section may not apply to your
router.
The section contains the following topics:
• Safety Warnings, page 3-9
• Preparing to Connect the Router, page 3-1
• Connecting a PC, Server, or Workstation, page 3-2
• Connecting a Phone, page 3-13
• Connecting an External Ethernet Switch, page 3-3
• Connecting the V.92 modem Port, page 3-15
• Connecting a Terminal or PC to the Console Port, page 3-4
• Connecting a Modem to the Console Port, page 3-5
• Connecting the 3G Card, page 3-18
• Installing the 3G Adapter for Extended Cable/Antenna, page 3-24
• Connecting a Data BRI Port, page 3-28
• Connecting an FE Line to an FE WAN Port, page 3-30
• Connecting a GE Line to an GE WAN Port, page 3-31
• Connecting an xDSL Line, page 3-31
• Connecting Power over Ethernet, page 3-34
• Connecting the AC Adapter, page 3-5
• Connecting an FXS Line, page 3-39
• Connecting an FXO Line, page 3-40
• Connecting a Voice ISDN BRI Line, page 3-42
• Verifying Connections, page 3-7
Note For compliance and safety information, see Regulatory Compliance and Safety Information Roadmap
that ships with the router and Regulatory Compliance and Safety Information for Cisco 800 Series
Routers.
ACT Green Network activity on FE Switch ports, GE WAN port, 3G
cellular interface, and serial interfaces.
Off No network activity.
Table 3-1 Verifying the Router Operation (continued)
Power and Link LEDs to Check Normal Patterns
