Appendix A Technical Specifications
Cisco 860, 880, 890 Series
Console and Auxiliary Port Connector Pinouts
Table A-19 lists the pinouts for the console and auxiliary port connectors.
FXS and FXO Port Connector Pinouts
Table A-20 lists the FXS and FXO connector pinouts.
VDSL2 Port Connector Pinouts
Table A-21 lists the VDSL2 connector pinouts.
Table A-19 Console and Auxiliary Port Connector Pinouts
RJ-45 Pin Function
1RTS
2DTR
3TXD
4 GND
5 GND
6RXD
7DSR
8CTS
Table A-20 FXS and FXO Connector Pinouts (RJ-11-to-RJ-45)
Pin Signal
1NC
2NC
3TIP
4RING
5NC
6NC
Table A-21 VDSL2 Connector Pinouts (RJ-11-to-RJ-45)
RJ-11 Pin Function
1Unused
2Unused
3TIP
4RING

Cisco 860 Series Specifications

General

VPN Support	Yes
Firewall	Yes
QoS	Yes
Data Link Protocol	Ethernet, Fast Ethernet
Remote Management Protocol	SNMP, Telnet, HTTP, HTTPS
Operating System	Cisco IOS
Device Type	Router
WAN Interfaces	1 x 10/100Base-TX - RJ-45
LAN Interfaces	4 x 10/100Base-TX - RJ-45
Connectivity Technology	Wired
Network / Transport Protocol	IPSec, TCP/IP
Features	DHCP support, NAT support, VLAN support, IPv6 support
Compliant Standards	IEEE 802.3, IEEE 802.3u
