Total
Power
Tray
N+N Redundancy Mode
in Watts (with Feed Loss)
N+1 Redundancy Mode in
Watts (with Single Supply
Loss)
Combined Mode in Watts
(No redundancy)
Total Power
Supply
6
3
50,40096,00010,080021
52,80010,0800105,60022
55,200105,600110,40023
57,600110,400115,20024
3
Power Tray 4, 5 and 6 are applicable for Cisco 8818 Router.
Note
Supported Optics
To determine which transceivers and cables are supported by this router, refer to the Transceiver Module
Group (TMG) Compatibility Matrix Tool:
https://tmgmatrix.cisco.com/home
• For QSFP-DD data sheets, refer to the Cisco 400G QSFP-DD Cable and Transceiver Modules Data
Sheet.
• For QSFP28 data sheets, refer to the Cisco 100GBASE QSFP-100G Modules Data Sheet.
• For QSFP+ data sheets, refer to the Cisco 40GBASE QSFP Modules Data Sheet.
Note
Hardware Installation Guide for Cisco 8800 Series Routers
11
Cisco 8800 Series Routers Overview
Supported Optics
