Cisco TelePresence System Quick Set C20 / C20 Plus and Profiles using C20 Administrator guide
D14637.04 Profile C20 and Quick Set C20 Administrator Guide TC4.0, November 2010.
Copyright © 2010 Cisco Systems, Inc. All rights reserved.
www.cisco.com
Optimal definition profiles
Under ideal lighting conditions the bandwidth requirements can
be substantially reduced with the optimal definitions profiles.
Generally, we recommend the Optimal Definition set at Normal.
If lighting conditions are good we recommend that you test
the endpoint on the various Optimal Definition settings before
deciding on a profile.
Go to Advanced configuration (menu on screen or web interface)
to set the optimal definition profile:
• Navigate to Video > Input > Source [1..n] >
OptimalDefinition > Profile and select a profile.
You can set a resolution threshold below which the maximum
frame rate will be 30 fps.
Go to Advanced configuration (menu on screen or web interface)
to set the threshold:
• Navigate to Video > Input > Source [1..n] >
OptimalDefinition > Threshold60fps and select a
threshold.
The video input quality settings must be set to Motion to ensure
the Optimal Definition to work. With the video input quality set
to Sharpness, the endpoint will transmit the highest resolution
possible, regardless of frame rate.
Go to Advanced configuration (menu on screen or web interface)
to set the input quality:
• Navigate to Video > Input > Source [1..n] > Quality and set
the video quality parameter.
You can read more about the video settings in the Advanced
configuration settings chapter. Go to:
Advanced configuration
High (720p60)
Typically used in dedicated video
conferencing rooms. Requires good
lighting conditions for a good overall
experience.
Under ideal conditions the bandwidth
requirements can be reduced by up to
50%.
Medium (w576p60)
Typically used in rooms with better
than normal, and consistent lighting.
The bandwidth requirements can be
reduced by up to 25%.
Normal (w448p60)
This setting is typically used in office
environments where the environment is
normal to poorly lit.
Generally, we recommend the Optimal
Definition set at Normal.
Optimaldefinitionprofilesforsystemssupporting1080p
w288p30 w448p30 w576p30 720p30 1080p30
Normal 256 kbit/s 512 kbit /s 768 kbit/s 1152 kbi t /s 2560 kbit/s
Medium 128 kbit/s 384 kbit/s 512 kbit /s 1152 kbit /s 1920 kbit/s
High 128 kbit/s 256 kbit/s 512 kbit /s 768 kbit/s 1472 kbit/s
Optimaldefinitionprofilesforsystemssupporting720p60
w144p60 w288p60 w448p60 w576p60 720p60
Normal 128 kbit/s 512 kbit/s 1152 k bi t /s 1472 kbit/s 2240 kbit/s
Medium 128 kbit/s 384 kbit/s 768 kbit/s 1152 kbi t /s 1920 kbit/s
High 128 kbit/s 256 kbit/s 512 kbit /s 768 kbit/s 1152 k b it /s
