Cisco TelePresence System Quick Set C20 / C20 Plus and Profiles using C20 Administrator guide
D14637.04 Profile C20 and Quick Set C20 Administrator Guide TC4.0, November 2010.
Copyright © 2010 Cisco Systems, Inc. All rights reserved.
www.cisco.com
DIMENSIONS
Height: 63.78” / 162 cm
Width: 38.58” / 98 cm
Depth: 6.7” / 17 cm
WEIGHT
Weight: 202.8 lbs / 92 kg
All specifications are subject to change without notice,
system specifics may vary.
All images in these materials are for representational
purposes only, actual products may differ.
TANDBERG and Expressway are registered trademarks
or trademarks of TANDBERG in the U.S. and other
countries.
All other trademarks are property of their respective
owners.
MTBFPRODUCTRELIABILITY/MTBF
The predicted reliability is expressed in the expected
random Mean Time Between Failures (MTBF) for the
electronic components based on the Power On Hours:
Power On Hours (POH) > 69 000 hours
Useful Life Cycle > 6 years
ISO 9001 certificate is available upon request
November 2010
DIRECTORYSERVICES
Support for Local directories (My Contacts)
Corporate Directory
Unlimited entries using Server directory supporting
LDAP and H.350
Unlimited number for Corporate directory (through Cisco
TelePresence Management Suite)
200 number local directory
Received Calls with Date and Time
Placed Calls with Date and Time
Missed Calls with Date and Time
POWER
Auto-sensing power supply
100-120/200-240 VAC, 60/50 Hz, 4.5 A max
Maximum power consumption: 390 W
OPERATINGTEMPERATUREANDHUMIDITY
0° C to 35° C (32° F to 95° F) ambient temperature
10% to 90% Relative Humidity (RH)
STORAGEANDTRANSPORTTEMPERATURE
-20° C to 60° C (-4° F to 140° F) at RH 10–90% (non-
condensing)
APPROVALS
EU/EEC
Directive 2006/95/EC (Low Voltage Directive)
–Standard EN 60950-1, 2ed
Directive 2004/108/EC (EMC Directive)
–Standard EN 55022, Class A
– Standard EN 55024
– Standard EN 61000-3-2/-3-3
Warning: This is a class A product. In a domestic
environment this product may cause radio interference
in which case the user may be required to take adequate
measures.
USA
Approved according to UL 60950-1
Complies with FCC15B Class A
Canada
Approved according to CAN/CSA C22.2 No. 60950-1
This Class A digital apparatus complies with Canadian
ICES-003.
Cet appareil numérique de la classe A est conforme à la
norme NMB-003 du Canada.
NETWORKINTERFACES
1 x LAN/Ethernet (RJ-45) 10/100/1000 Mbit
OTHERINTERFACES
USB host for future usage
PRECISIONHD1080P12XCAMERA
1/3” CMOS
12 x zoom
+15°/-25° tilt, +/- 90° pan
43.5° vertical field of view
72° horizontal field of view
Focus distance 0.3 m–infinity
1920 x 1080 pixels progressive @ 60fps
Other formats supported (configurable through Dip-
switch):
1920 x 1080@60 Hz (HDMI only)
1920 x 1080@50 Hz (HDMI only)
1920 x 1080@30 Hz
1920 x 1080@25 Hz
1280 x 720@60 Hz
1280 x 720@50 Hz
1280 x 720@30 Hz
1280 x 720@25 Hz
Automatic or manual focus/brightness/white balance
Far-end camera control
Dual HDMI and HD-SDI output
SYSTEMMANAGEMENT
Support for the Cisco TelePresence Management Suite
Total management via embedded SNMP, Telnet, SSH,
XML, SOAP
Remote software upload: via web server, SCP, HTTP,
HTTPS
Remote control and on-screen menu system
* requires option
Profile 42”/52”, continued...
