Technical specifications
Quick Set C20/C20 Plus
SETDELIVEREDCOMPLETEWITH:
Codec C20, PrecisionHD 1080p 4X or 12X camera,
Performance Mic 20, remote control, cables and power
supply
BANDWIDTH
H.323/SIP up to 6 Mbps point-to-point
FIREWALLTRAVERSAL
TANDBERG Expressway™ Technology
H.460.18, H.460.19 Firewall Traversal
VIDEOSTANDARDS
H.261, H.263, H.263+, H.264
VIDEOFEATURES
Native 16:9 Widescreen
Advanced Screen Layouts
Intelligent Video Management
Local Auto Layout
VIDEOINPUTS(2INPUTS)
1 X HDMI input, supported formats:
1920 x 1080@60, 59.94 Hz (1080p60)
1920 x 1080@50 Hz (1080p50)
1920 x 1080@30, 29.97 Hz (1080p30)
1920 x 1080@25 Hz (1080p25)
1920 x 1080@24, 23.97 Hz (1080p24)
1920 x 1200@50 Hz (WUXGA)
1680 x 1050@60 Hz (WSXGA+)
1600 x 1200@50, 60 Hz (UXGA)
1440 X 900@60 Hz (WXGA+)
1400 x 1050@60, 75 Hz
1366 x 768@60 Hz
1360 x 768@60 Hz
1280 x 1024@60, 75, 85 Hz (SXGA)
1280 x 960@60, 85 Hz
1280 x 800@60 Hz (WXGA)
1280 x 768@60, 75, 85 Hz (WXGA)
1280 x 720@60, 59.94 Hz (720p60)
1280 x 720@50 Hz (720p50)
1152 x 864@75 Hz
1024 x 768@60, 70, 75, 85 Hz (XGA)
848 x 480@60 Hz (576p50)
800 x 600@56, 60, 72, 75, 85 Hz (SVGA)
720 x 576@50 Hz
720 x 480@60, 59.94 Hz (480p60)
640 x 480@60, 72, 75, 85 Hz (VGA)
1 X DVI-I input, supported formats:
Digital (DVI-D):
Same as HDMI, ref. above.
Analog RGB (DVI-A):
1920 x 1080@60 Hz (1080p60)
1920 x 1200@50 Hz (WUXGA)
1680 x 1050@60 Hz (WSXGA+)
1600 x 1200@60 Hz (UXGA)
1440 x 900@60 Hz (WXGA+)
1400 x 1050@60, 75 Hz
1366 x 768@60 Hz
1360 x 768@60 Hz
1280 x 1024@60, 75, 85 Hz (SXGA)
1280 x 960@60, 85 Hz
1280 x 800@60 Hz (WXGA)
1280 x 768@60, 75, 85 Hz (WXGA)
1280 x 720@60 Hz (720p60)
1152 x 864@75 Hz
1024 x 768@60, 70, 75, 85 Hz (XGA)
848 x 480@60 Hz
800 x 600@56, 60, 72, 75, 85 Hz (SVGA)
720 x 576@50 Hz
720 x 480@60, 59.94 Hz (480p60)
640 x 480@60, 72, 75, 85 Hz (VGA)
Analog YPbPr (DVI-A):
1920 x 1080@60 Hz (1080p60)
1920 x 1080@50 Hz (1080p50)
1920 x 1080@30 Hz (1080p30)
1920 x 1080@25 Hz (1080p25)
1280 x 720@60 Hz (720p60)
1280 x 720@50 Hz (720p50)
1280 x 720@30 Hz (720p30)
720 x 576@50 Hz (576p50)
720 x 480@60 Hz (480p60)
Extended Display Identification Data (EDID)
VIDEOOUTPUTS(2OUTPUTS)
2 X HDMI output, supported formats:
1920 x 1080@60 Hz (1080p60)
1920 x 1200@60Hz (WUXGA)
1600 x 1200@60 Hz (UXGA)
1366 x 768@60 Hz
1360 x 768@60 Hz
1280 x 720@60 Hz (720p60)
1280 x 1024@60 Hz (SXGA)
1280 x 768@60 Hz (WXGA)
1024 x 768@60 Hz (XGA)
800 x 600@60 Hz (SVGA)
640 x 480@60 Hz (VGA)
VESA Monitor Power Management
LIVEVIDEORESOLUTIONS(ENCODE/DECODE)
176 x 144@30 fps (QCIF)
352 x 288@30 fps (CIF)
512 x 288@30 fps (w288p)
576 x 448@30 fps (448p)
768 x 448@30 fps (w448p)
704 x 576@30 fps (4CIF)
1024 x 576@30 fps (w576p)
640 x 480@30 fps (VGA)
800 x 600@30 fps (SVGA)
1024 x 768@30 fps (XGA)
1280 x 1024@30 fps (SXGA)
1280 x 720@30 fps (720p30)
1920 x 1080@30 fps (1080p30)**
1280 x 768@30 fps (WXGA)
1440 x 900@30 fps (WXGA+)
1680 x 1050@30 fps (WSXGA+)
1600 x 1200@30 fps (UXGA)
512 x 288@60 fps (w288p60)**
768 x 448@60 fps (w448p60)**
1024 x 576@60 fps (w576p60)**
1280 x 720@60 fps (720p60)**
1920x1200@20fps (WUXGA)
AUDIOSTANDARDS
G.711, G.722, G.722.1, 64 bit & 128 bit MPEG4 AAC-LD
AUDIOFEATURES
CD-Quality 20 KHz Mono
1 x Acoustic Echo Canceller
Automatic Gain Control (AGC)
Automatic Noise Reduction
Active Lip Synchronization
AUDIOINPUTS(4INPUTS)
2 x Microphone, 4 pin MiniJack
2 x RCA/Phono (mixed to mono)
AUDIOOUTPUTS(3OUTPUTS)
2 x RCA/Phono (dual mono)
1 x HDMI, digital, main audio
DUAL STREAM
H.239 (H.323) dual stream
BFCP (SIP) dual stream
Support resolutions up to WXGA (1280 x 768)
PROTOCOLS
H.323
SIP
EMBEDDEDENCRYPTION
H.323/SIP point-to-point
Standards-based: H.235 v2 & v3 and AES
Automatic key generation and exchange
Supported in Dual Stream
IPNETWORKFEATURES
DNS lookup for service configuration
Differentiated Services (QoS)
IP adaptive bandwidth management (including flow
control)
Auto gatekeeper discovery
Dynamic playout and lip-sync buffering
H.245 DTMF tones in H.323
Date and Time support via NTP
Packet Loss based Downspeeding
URI Dialing
TCP/IP
DHCP
Direct DNS dialing
802.1x network authentication
SECURITYFEATURES
Management via HTTPS and SSH
IP Administration Password
Menu Administration Password
Disable IP services
Network Settings protection
