Cisco TelePresence System Quick Set C20 / C20 Plus and Profiles using C20 Administrator guide
D14637.04 Profile C20 and Quick Set C20 Administrator Guide TC4.0, November 2010.
Copyright © 2010 Cisco Systems, Inc. All rights reserved.
www.cisco.com
Received Calls with Date and Time
Placed Calls with Date and Time
Missed Calls with Date and Time
POWER
Auto-sensing power supply
100–240 VAC, 50/60 Hz
45 watts max. for codec and main camera
OPERATINGTEMPERATUREANDHUMIDITY
0° C to 35° C (32° F to 95° F) ambient temperature
10% to 90% Relative Humidity (RH)
STORAGEANDTRANSPORTTEMPERATURE
-20° C to 60° C (-4° F to 140° F) at RH 10–90% (non-
condensing)
APPROVALS
EU/EEC
Directive 2006/95/EC (Low Voltage Directive)
– Standard EN 60950-1
Camera Rev.03 (rating label):
EU/EEC
Directive 2004/108/EC (EMC Directive)
– Standard EN 55022, Class A
– Standard EN 55024
– Standard EN 61000-3-2/-3-3.
Warning: This is a class A product. In a domestic
environment this product may cause radio
interference in which case the user may be required
to take adequate measures.
USA
Approved according to UL 60950-1
Complies with FCC15B Class A
Canada
Approved according to CAN/CSA-C22.2 No. 60950-1
This Class A digital apparatus complies with
Canadian ICES-003.
Cet appareil numérique de la classe A est conforme à
la norme NMB-003 du Canada.
Camera Rev.04 (rating label):
EU/EEC
Directive 2004/108/EC (EMC Directive)
– Standard EN 55022, Class B
– Standard EN 55024
– Standard EN 61000-3-2/-3-3
USA
Approved according to UL 60950-1
Complies with FCC15B Class A
Canada
Approved according to CAN/CSA-C22.2 No. 60950-1
This Class B digital apparatus complies with
Canadian ICES-003.
Cet appareil numérique de la classe B est conforme à
la norme NMB-003 du Canada.
DIMENSIONS
Codec C20:
Length: 15.35 in/39.0 cm
Height: 1.18 in/3.0 cm
Depth: 5.0 in/12.7 cm
WEIGHT
Codec C20:
Weight: 4.0 lbs/1.8 kg
All specifications are subject to change without notice,
system specifics may vary.
All images in these materials are for representational
purposes only, actual products may differ.
TANDBERG and Expressway are registered trademarks
or trademarks of TANDBERG in the U.S. and other
countries.
All other trademarks are property of their respective
owners.
MTBFPRODUCTRELIABILITY/MTBF
The predicted reliability is expressed in the expected
random Mean Time Between Failures (MTBF) for the
electronic components based on the Power On Hours:
Power On Hours (POH) > 69 000 hours
Useful Life Cycle > 6 years
ISO 9001 certificate is available upon request
November 2010
Depth: 13.8 cm/5.43”
Weight: 1.44 kg/3.95 lbs
PrecisionHD 1080p 4X* CAMERA
NOTE: This is an interim version available for a limited
period of time.*
1080p60 True High Definition
4 x optical zoom with smooth and quiet handling
HDMI and HD-SDI outputs with ability to share picture
simultaneously through both ports
Mount upside down—camera orientation automatically
detected and picture flipped
1/3” CMOS
Pan speed: 100º/s, range: -90º to +90º
Tilt speed: 30º/s, range: -25º to +15º
43.5° vertical field of view
72° horizontal field of view
Focus distance 0.3 m–infinity
1920 x 1080 pixels progressive @ 30fps
Other formats supported (configurable through Dip-
switch):
1920 x 1080@30 Hz
1920 x 1080@25 Hz
1280 x 720@30 Hz
1280 x 720@25 Hz
Automatic or manual focus, brightness, and white balance
Far-end camera control
Daisy-chain support (can only be in the end of a chain)
Height (at max tilt): 17.2 cm/6.8”
Width: 22 cm/8.7”
Depth: 14.7 cm/5.8”
Weight: 1.8 kg/3.17 lbs
SYSTEMMANAGEMENT
Support for the Cisco TelePresence Management Suite
Total management via embedded SNMP, Telnet, SSH,
XML, SOAP
Remote software upload: via web server, SCP, HTTP,
HTTPS
Remote control and on-screen menu system
DIRECTORYSERVICES
Support for Local directories (My Contacts)
Corporate Directory
Unlimited entries using Server directory supporting
LDAP and H.350
Unlimited number for Corporate directory (through Cisco
TelePresence Management Suite)
200 number local directory
NETWORKINTERFACES
1 x LAN/Ethernet (RJ-45) 10/100/1000 Mbit
OTHERINTERFACES
USB host for future usage
PRECISIONHD1080P12XCAMERA
1/3” CMOS
12 x zoom
+15°/-25° tilt, +/- 90° pan
43.5° vertical field of view
72° horizontal field of view
Focus distance 0.3 m–infinity
1920 x 1080 pixels progressive @ 60fps
Other formats supported (configurable through Dip-
switch):
1920 x 1080@60 Hz (HDMI only)
1920 x 1080@50 Hz (HDMI only)
1920 x 1080@30 Hz
1920 x 1080@25 Hz
1280 x 720@60 Hz
1280 x 720@50 Hz
1280 x 720@30 Hz
1280 x 720@25 Hz
Automatic or manual focus/brightness/white balance
Far-end camera control
Dual HDMI and HD-SDI output
Upside-down mounting with automatic flipping of picture
PRECISIONHD1080P4XCAMERA
1080p30/720p60 True High Definition
4 x optical zoom
HDMI output
Mount upside down—(select option through VISCA™)
Pan speed: 100º/s, range: -90º to +90º
Tilt speed: 30º/s, range: -25º to +15º
43.5° vertical field of view
70° horizontal field of view
Focus distance 0.3 m–infinity
1920 x 1080 pixels progressive @ 30fps
1280 x 720 pixels progressive @ 60fps
Automatic or manual focus, brightness, and white balance
Height (at max tilt): 15.1 cm/5.94”
Width: 21.2 cm/8.35”
* The early shipments of the Quick Set C20 came with an
interim version of the PrecisionHD 1080p 4X camera (the
PrecisionHD 1080p 4X* camera).
** requires option
Quick Set C20/C20 Plus, continued...
Contents
Contact us
Web interface
Advanced configuration
Introduction
Password protection
Appendices
Appendices

Cisco C20 Specifications

General

Encryption	AES
Frame Rate	Up to 30 fps
Firewall Traversal	Yes
Connectivity	Wired
Video Standards	H.264
Audio Standards	G.711, G.722
Network Interfaces	10/100/1000 Ethernet
Content Sharing	Yes
Product Type	Video conferencing system
Network Protocols	H.323, SIP
Interfaces	Ethernet
Video Resolution	720p
