Cisco C20 Administrator's Guide

8
Cisco TelePresence System Quick Set C20 / C20 Plus and Profiles using C20 Administrator guide
D14637.04 Profile C20 and Quick Set C20 Administrator Guide TC4.0, November 2010.
Copyright © 2010 Cisco Systems, Inc. All rights reserved.
www.cisco.com
Power cable
Mic cables
PC cable
Ethernet cable
Profile 42”
2 x Microphones
with cables
Remote control
with 4 batteries
System overview
Profile 42” using Codec C20
See the installation sheet for your Profile system for instructions
on how to install the system.
Codec C20
• Full HD video.
• High resolution data sharing.
• Rich I/O capabilities.
PrecisionHD 1080p camera
Full HD Camera designed for visual communication with:
• 12 x optical zoom.
• Fast and precise pan, tilt and zoom.
Monitor
42” Full HD LCD, 16:9, 1080 x 1920 resolution.
Audio module
Wide band audio module supporting:
• 20 kHz AAC-LD.
• 1 echo canceller.
Audio amplifier
Optimized DNAM for the Profile system, providing
crystal clear and natural audio.
Microphones
2 x Microphones.
Remote control
Remote Control TRC5, with AAA batteries.
Foot stand
Stand alone, wheelbase or wall mounting foot stand.
In the base module:
• Audio amplifier (DNAM)
• Codec C20
PrecisionHD 1080p camera
Monitor 42’’
Full HD LCD
Foot stand (stand alone,
wheelbase or wall mounting foot
module)
