Cisco Catalyst 2960-CX User Manual

Step 2
Slide the retainer around the AC power cord, and pass it around the loop on the switch.
Figure 30: Inserting the Retainer through the Lanced Loop
Sleeve for thinner power cords3AC power cord1
Loop4Power cord retainer2
Step 3
Slide the retainer through the first latch.
Figure 31: Sliding the Retainer Through the Latch
Latch3AC power cord1
Smaller sleeve for thin power cords2
Catalyst 3560-CX and 2960-CX Switch Hardware Installation Guide
37
Switch Installation
Installing the Power Cord Retainer (Optional)

Cisco Catalyst 2960-CX Specifications

General

PoE	No
DRAM	512 MB
MAC Address Table Size	16, 000 entries
Stacking	No
Model	Cisco Catalyst 2960-CX
Ports	8 x 10/100/1000 Ethernet ports
Uplink Interfaces	2 x 1G SFP
Power Input	100 to 240 VAC
Operating Temperature	0°C to 40°C (32°F to 104°F)
Storage Temperature	-25°C to 70°C (-13°F to 158°F)
Power Consumption	15W
Relative Humidity	10 to 95% noncondensing
