IN-3
Catalyst 2970 Switch Hardware Installation Guide
OL-6422-01
Index
1000BASE-T SFP module ports 2-32
connectivity problems 3-5
pinout
four twisted-pair, 1000BASE-T ports
B-6
D
DC power
RPS
1-2
Device Manager xvi, 1-14
to configure switch 2-34
diagnosing problems 3-3
document conventions x
duplex LED 1-9
E
electrical noise, avoiding 2-6
examples, network configuration 1-1
Express Setup
accessing CLI by using
C-2
F
features 1-1 to 1-2
front panel
10/100 /1000 ports
1-4
clearance 2-6
description 1-3 to 1-10
LEDs 1-6 to 1-10
SFP module ports 1-6
H
HP OpenView 1-14
humidity, relative A-1
I
installation
assigning the IP Address
C-8
connecting to a power source C-7
rack mounting 2-10 to 2-19
site requirements 2-5
starting the terminal emulation software C-6
table or shelf mounting 2-23
wall mounting 2-20
See also procedures
installing SFP modules
2-24 to 2-26
IOS command-line interface 1-14
L
LEDs
color meanings
1-8
duplex 1-9
front panel 1-7
interpreting 1-8
