Rear Panel Description
Rear Panel Description
The Catalyst 2970G-24T switch rear panel has an AC power connector, an RPS
connector, and an RJ-45 console port. (See Figure 1-4.)
Figure 1-4 Catalyst 2970G-24T Switch Rear Panel
The Catalyst 2970G-24TS switch rear panel has an AC power connector, an RPS
connector, and an RJ-45 console port. (See Figure 1-5.)
1 RJ-45 console port 3 AC power connector
2 Fan exhaust 4 RPS connector
RATING
100-240V ~
1.6A-0.9A, 50-60 HZ
DC INPUTS FOR REMOTE
POWER SUPPLY
SPECIFIED IN MANUAL
+12v @13A
CONSOLE
1 2 3 4
87620
