B-1
Catalyst 2970 Switch Hardware Installation Guide
OL-6422-01
APPENDIX
B
Connector and Cable Specifications
This appendix describes the Catalyst 2970 switch ports and the cables and
adapters that you use to connect the switch to other devices.
Connector Specifications
These sections describe the connectors used with the Catalyst 2970 switch.
10/100/1000 Ports
The 10/100/1000 Ethernet ports on the Catalyst 2970 switch use standard RJ-45
connectors. Figure B-1 shows the pinout.
