Table 40: Console Port Signaling with a DB-9 Adapter

Console DeviceRJ-45-to-DB-9 Terminal AdapterSwitch Console Port (DTE)

SignalDB-9 PinSignal

CTS8RTS

DSR6DTR

RxD2TxD

GND5GND

TxD3RxD

DTR4DSR

RTS7CTS

Table 41: Console Port Signaling with a DB-25 Adapter

Console DeviceRJ-45-to-DB-25 Terminal AdapterSwitch Console Port (DTE)

SignalDB-25 PinSignal

CTS5RTS

DSR6DTR

RxD3TxD

GND7GND

TxD2RxD

DTR20DSR

RTS4CTS

Catalyst 3850 Switch Hardware Installation Guide

OL-26779-05124
