Figure 7: Switch Front Panel LEDs for the WS-C3850-12S, WS-C3850-24S, WS-C3850-12XS, and WS-C3850-24XS Switches
USB mini-Type B console
port LED
6UID (blue beacon)1
SYST (system)7STAT (status)2
ACTV (active)8DUPLX (duplex)3
XPS
8
9SPEED4
S-PWR (StackPower)10STACK5
8
XPS = expandable power system.
Figure 8: Switch Front Panel LEDs for the WS-C3850-48XS Switches
Catalyst 3850 Switch Hardware Installation Guide
15OL-26779-05
Product Overview
LEDs
