AC OK (input) status
LED
9MGMT (RJ-45
10/100/1000 management
port)
3
PS OK (output) status
LED
10RESET button4
Power supply modules
(AC power supply
modules shown)
11BEACON LED5
Fan module6
Figure 13: WS-C3850-48XS Switches Switch Rear Panel
Fan module5Ground connector1
Catalyst 3850 Switch Hardware Installation Guide
OL-26779-0524
Product Overview
Rear Panel
