RPL-Tail-end-Extranet supported.
•
Customer-RP-discovery (Embedded-RP, AutoRP & BSR) is supported.
•
Inter-AS Option A supported. Options B and C not supported.
•
All PEs must have a unique BGP Route Distinguisher (RD) value. To configure BGP RD value, refer
Cisco IOS XR Routing Configuration Guide for the Cisco CRS Router .
Whenever multicast stream crosses configured threshold on encap PE(Head PE), S-PMSI is announced.
Core tunnel is static P2MP-TE tunnel configured under route-policy for the stream. Static P2MP-TE data
mdt is implemented in such a way that it can work with dynamic data mdt, dynamic default mdtand default
static P2MP.
Note
Profile 17: Rosen-mLDP-P2MP with BGP AD/PIM C-multicast Routing
These are the characteristics of this profile:
•
Full mesh of P2MP mLDP core-tree as the Default-MDT, with PIM C-multicast Routing.
•
All UMH options supported.
•
Default and Data MDT supported.
•
Customer traffic can be SM, SSM , or Bidir (separate-partitioned-mdt).
•
RPL-Extranet, Hub & Spoke supported.
•
Customer-RP-discovery (Embedded-RP, AutoRP & BSR) is supported.
•
Inter-AS Option A, B and C supported.
Profile 18 : Rosen-Static-P2MP-TE with BGP AD/PIM C-multicast Routing
These are the characteristics of this profile:
•
Full mesh of Static-P2MP-TE core-trees, as the Default-MDT, with PIM C-multicast Routing.
•
All UMH options supported.
•
Default MDT supported; Data MDT is not supported.
•
Customer traffic can be SM, SSM .
•
RPL-Extranet, Hub & Spoke supported.
•
Customer-RP-discovery (Embedded-RP, AutoRP & BSR) is supported.
•
Inter-AS Option A supported. Options B and C not supported.
Profile 20 : Rosen-P2MP-TE with BGP AD/PIM C-multicast Routing
These are the characteristics of this profile:
•
Dynamic P2MP-TE tunnels setup on demand, with PIM C-multicast Routing
•
All UMH options supported.
