Select Yes to listen to MPEG over IP streams
sent to a specific multicast IP address (group).
Otherwise, select No to listen to the unicast
MPEG over IP streams sent to the IP addresses
of the Data1 and Data2 ports.
If isMulticast is set to Yes, enter the multicast
IP address.
Valid multicast IP address
Type of expected FEC streams for the decoder
to analyze and use.
None - All FEC streams
are dropped.
1D - Column stream is
expected.
2D - Column and row
streams are expected.
Select the source (host) filtering mode.
None - All streams sent to
a specific destination IP
address (multicast or
unicast) and destination
TS and FEC UDP ports are
received, without source
restrictions.
White List - The unit will
only receive streams from
the defined list of
hosts/servers (Idx and IP
Address). It will reject the
streams received from the
host/servers that are not
defined on the list.
Black List - The unit will
reject the streams received
from the defined list of
hosts/servers (Idx and IP
Address).
The transport stream UDP port number. For
RTP port, enter an even port number. For UDP
port, you can enter an even or odd port
number.
Note: FEC is only supported for RTP transport
streams.
If FEC is set to 1D or 2D, set the FEC
destination UDP port number of the column
FEC stream.
