Assigning a Program Channel to a PE (Program Entry)
19
Assigning a Program Channel to a PE (Program
Entry)
1 At the start-up screen, PE1 is initially displayed.
2 Press ADV and use the keys to scroll through the available program entries.
3 Press ADV again to select the channel number.
4 Use the keys to scroll through the available program channels or directly
enter the channel number using the 0 to 9 keys; press SELECT to save the
channel selection.
Important: In addition to ASI out availability on all models, your unit will be
configured for either HD-SDI or MOIP output. Please follow the procedure for your
model to configure the outputs.
