Cisco D9854-I User Manual

Video Inputs/Outputs and Processing
379
Linearity
5-step
3%
3%
Interchannel Delay
100% Color Bars
2 ns
2 ns
DC Offset
± 50 mV
± 50 mV
Return Loss
DC to 30 MHz, -20 dB
DC to 30 MHz, -20 dB
Aspect Ratio
Item
Specification
Aspect Ratio Conversions for Down-
Conversion
Aspect Ratio Conversions for SD Programs
4:3
16:9
4:3
16:9
16:9 Letterbox
14:9 Letterbox Center
Center Cutout
16:9 Letterbox
14:9 Letterbox Center
Cutout
Scale to 16:9
Embedded Data in SDI
VBI Processing
Item
Specification
Closed Captioning
Output formats
SMPTE-334M embedded in HD-SDI
Embedded Audio
Item
Specification
Format
According to SMPTE-299M
Audio sampling frequency
48 kHz locked to the video. According to
SMPTE-272M
Resolution
20 bits
