Appendix A
Technical Specifications
380
Audio Outputs
Analog Audio Outputs
Item
Specification
Number of Channels
2 stereo pairs/4 mono channels, 5.1 channel
downmix Audio decompression: MPEG or
Dolby Digital. HE-AAC single stereo pair or
Dolby Digital Plus single stereo pair available as
future software download.
Frequency Response
±0.5 dB, 20 Hz to 20 kHz (ref., 100 kilohms)
Total Harmonic Distortion
< 0.3% at 1 kHz (ref. 100 kilohms)
Dynamic Range
85 dB (CCIR/Arm weighting)
Crosstalk
80 dB at 1 kHz (typical)
Digital Audio Outputs
Item
Specification
Number of Channels
2 (one stereo channel each)
Format
AES-3id
Connector
BNC
Conditional Access
Item
Specification
PowerVu CA
DES or DVB
DVB Scrambling
BISS Mode 1, BISS Mode E
DVB-CI
Interface: 2 CI slots - EN 50221
For a list of all the supported CAMs, see Common Interface Modules
(on page 41).
