Chapter 4 Front Panel Operation
88
The IP menu has the following structure:
IP
Menu Item
Description
Parameters
Port ID
Select the Ethernet interface to
configure.
The D9854 has two interface ports.
Interface 1 is the control and
management interface and interface 2
is the data interface.
The D9854-I has three interface ports.
Interface 1 is the control and
management interface and interface 2
and interface 3 are data interfaces.
Description
Sets the description or name for the
Ethernet interface.
Up to 20 alphanumeric characters in
length.
V4/V6
Select the IP protocol.
Only IPv4 is currently supported.
IP Address
Sets the IPv4 IP address for the
interface.
12 digits in length (###.###.###.###)
Mask
Sets the number of CIDR (Classless
Inter-Domain Routing) bits in the
network mask.
8 to 30
