Chapter 5 Web GUI Setup and Monitoring
The output will be generated according to the DPM settings on the
ASI Digital Program Mapping page. This is a manual control
setting.
A message appears to confirm that you want to resynchronize the output
changes and PIDs to match the selected input programs. Click Yes.
If a conflict occurs and Enable Auto Map for Collision is set to No, a detailed list
of all the conflicts is displayed in the Output Channel and PID Conflicts table
when you click View Conflicts. You can then resolve the conflicts manually. If a
conflict occurs and Enable Auto Map for Collision is set to Yes, a message that
the conflicts will be fixed automatically and the Output Channel and PID
Conflicts table is empty.
ï‚¡ For channel conflicts, the system will only automatically change the
duplicated output channel numbers. If both PE actions are set to Map, the
output channel number of the higher PE is changed. Otherwise, the output
channel number of the mapped PE is changed. The new channel number
selected is the next channel number that does not appear in the current PAT
or belong to any other PEs.
ï‚¡ For PID conflicts, the system will only automatically change the duplicated
output PID numbers. If both PE actions are set to Map, the output PID
number of the higher PE is changed. Otherwise, the output PID number of
the mapped PE is changed. For example, if the PMT PID of PE1 matches the
ES PID of PE2, the ES PID of PE2 is changed. The new PID number selected is
the next number that does not appear in the output of any PE and it is not in
the current transport input.
Click Apply to save the resolved conflict changes.
5 The Mode Status indicates the current DPM configuration change by a user after
changing the Output Mode. The following is a list of possible statuses:
No changes were made after setting a new Output Mode.
