Cisco D9854-I User Manual

D9854/D9854-I Receiver Rear Connector Panel
31
Connector
Description
Type
ASI Input
Asynchronous Serial Interface Input.
BNC
ASI Output
One Asynchronous Serial Interface Output.
BNC
TS Outputs
TS Inputs/Outputs
(D9854-I only)
This is for the MPEGoIP and MPE outputs.
The MPEGoIP output transmits the
decrypted transport stream encapsulated in
IP packets to a groomer for distribution. The
MPE output receives and outputs the IP
data packets from the incoming transport
stream.
The MPEGoIP input (D9854-I only) allows
the decoder to receive its streams from the
terrestrial IP network.
RJ-45
Management
Supports the following network protocols:
Telnet, SSHv2, HTTP, HTTPS, SNMPv2,
Syslog/DTX, SNTP, FTP (client side), TFTP,
and MPEGoIP output (D9854 only).
RJ-45
HD-SDI Outputs
M1 and M2 provide HD serial digital video
with embedded audio output for HD
applications according to SMPTE-292M.
BNC
RS-232 Data
RS-232 data output: 7 bits, even parity, 1
stop bit, up to 38.4 kb/s. These outputs are
user-configurable via the Setup menu on
the front panel.
9-pin sub-D female
Cue Tone/Cue Trigger
Relay Outputs
Program relay provides programmed
responses for alarms, cue trigger states for
ad-insertion equipment, or a cue tone
output for connection to ad-insertion
equipment.
15-pin sub-D female
Composite Video
Outputs
CVBS 1 and CVBS 2 provide two identical
SD composite video outputs for monitoring
applications.
BNC
Component Video
Outputs
SD to HD upconverted component video
output for HD monitoring applications.
BNC
AES-3id Audio Outputs
AES-3id outputs. One output for each stereo
channel.
BNC
Balanced Audio Outputs
Audio 1 and Audio 2 provide two stereo
pairs or four mono channels.
Terminal Blocks
Ground
Screw.
Grounding point for
the receiver
Power
AC power.
IEC 60320 Sheet 14
