Cisco IE-3000-8TC Hardware Installation Guide

1-13
Cisco IE 3000 Switch Hardware Installation Guide
OL-13017-01
Chapter 1 Overview
Power Converter (Optional)
Figure 1-11 Cisco IE 3000 Switch Rear Panel
Power Converter (Optional)
The switch can be used with an optional AC/DC power converter. The power converter
(PWR-IE3000-AC) can supply 24-VDC power to one switch and up to two modules. The power
converter is mounted on the side of a switch and provides power to the switch through a preassembled
power cable.
Note The power converter (PWR-IE3000-AC=) is sold separately.
You can get a replacement power cable (PWR-IE3000-CLP=) by calling Cisco Technical Support.
For installation and connection procedures for the power converter, see the “Connecting the Switch to
the Power Converter” section on page 2-44.
1 DIN rail latch 2 Foot in recessed position
1
2
201697

Cisco IE-3000-8TC Specifications

General

Switching Capacity	16 Gbps
MAC Address Table Size	8000
Uplink Ports	2 x 10/100/1000Base-T or SFP (Small Form-Factor Pluggable)
Operating Temperature	-40°C to 70°C
Mounting	DIN rail
Ports	8 x Ethernet 10/100Base-TX ports
Jumbo Frame Support	Yes
