Cisco IE-3000-8TC Hardware Installation Guide

2-6
Cisco IE 3000 Switch Hardware Installation Guide
OL-13017-01
Chapter 2 Switch Installation
Adding Modules to the Switch
Table 2-1 lists the port combinations using switch and expansion modules.
Figure 2-1 shows example combinations of the Cisco IE-3000-4TC switch and expansion modules. Even
though the example configurations in Figure 2-1 show a Cisco IE-3000-4TC switch, the same
combinations of expansion modules can be used with a Cisco IE-3000-8TC switch.
Ta b l e 2-1 Switch and Expansion Module Examples
Port Type Switch and Expansion Modules Combination
10/100FE 100FX Cisco IE-3000-4TC
4 1 Cisco IE-3000-4TC
8 1 Cisco IE-3000-8TC
4 8 1 Cisco IE-3000-4TC and 1 Cisco IEM-3000-8FM
12 1 Cisco IE-3000-4TC and 1 Cisco IEM-3000-8TM
8 8 1 Cisco IE-3000-8TC and 1 Cisco IEM-3000-8FM
16 1 Cisco IE-3000-8TC and 1 Cisco IEM-3000-8TM
12 8 1 Cisco IE-3000-4TC and 1 Cisco IEM-3000-8TM and 1 Cisco IEM-3000-8FM
20 1 Cisco IE-3000-4TC and 2 Cisco IEM-3000-8TM
16 8 1 Cisco IE-3000-8TC and 1 Cisco IEM-3000-8TM and 1 Cisco IEM-3000-8FM
24 1 Cisco IE-3000-8TC and 2 Cisco IEM-3000-8TM

Cisco IE-3000-8TC Specifications

General

Switching Capacity	16 Gbps
MAC Address Table Size	8000
Uplink Ports	2 x 10/100/1000Base-T or SFP (Small Form-Factor Pluggable)
Operating Temperature	-40°C to 70°C
Mounting	DIN rail
Ports	8 x Ethernet 10/100Base-TX ports
Jumbo Frame Support	Yes
