Cisco IR1101 Hardware Installation Guide

Supported Antennas for the IR1101
All of the currently supported antennas are broken down by functional groups.
Cellular 2G/3G/4G Antennas
Antenna Frequency Band Support and
Gain
RF ConnectorsPart Number/ Description
4G/LTE 698-960, 1448-1511, 1710-2400,
2500-2700 MHz
2.6 dBi typical, 3.8 dBi max 698-960 MHz
3.8 dBi typical, 4.3 dBi max 1448-1551
MHz
4.6 dBi typical, 5.5 dBi max 1710-2700
MHz
2 x 4G/LTE,
TNC(m)
1 x GPS
SMA(m)
Cisco Cellular and GPS 3-in-1 Vehicle Mount
and Fixed Infrastructure Antenna
(ANT-3-4G2G1-O).
Fixed Infrastructure Antenna with three ports;
two port 2G/3G/4G and one port GPS Vehicle
Mount.
4G/LTE 698-960, 1710-2700 MHz
2.5 dBi typical 698-960 MHz
2.5 dBi typical 1710-2700 MHz
2 x 4G/LTE,
SMA(m)
1 x GPS
SMA(m)
Cisco Dual LTE-Single GPS Multi-band Antenna
(4G-LTE-ANTM-O-3-B).
Integrated indoor and outdoor Antenna with three
ports; two ports for 2G, 3G, 4G/LTE and one port
for GPS.
4G/LTE:
698-960,1448-1511,1710-2400,2500-2700
MHz
2.6 dBi typical, 3.8 dBi max 698-960 MHz
3.8 dBi typical, 4.3 dBi max 1448-1511
MHz
4.6 dBi typical, 5.5 dBi max 1710-2700
MHz
No GPS element and no WiFi.
2 x 4G/LTE,
TNC(m)
Cisco Cellular 2-in-1 Vehicle Mount and Fixed
Infrastructure Antenna (ANT-2-4G2-O).
Two port 2G/3G/4G antenna with two elements.
This dual port LTE antenna does not have an
active GPS antenna (compared to
ANT-3-4G2G1-O which does), and is useful for
cases when there is no GPS required, or when
GPS is connected to a completely separate GPS
antenna.
1.5 dBi 698-960 MHz
2 dBi 1448-1511 MHz
3.5 dBi 1710-2700 MHz
N(f)Cisco Outdoor Omnidirectional Antenna for
2G/3G/4G Cellular (ANT-4G-OMNI-OUT-N).
Outdoor Omnidirectional Antenna for 2G/3G/4G
Cellular antenna is designed to cover domestic
LTE700/Cellular/PCS/AWS/MDS, WiMAX
2300/2500, and
GSM900/GSM1800/UMTS/LTE2600 bands.
IR1101 Industrial Integrated Services Router Hardware Installation Guide
45
Antenna Selection and Installation
Supported Antennas for the IR1101

Cisco IR1101 Specifications

General

DSL WAN	No
Ethernet WAN	Yes
SIM card slot	-
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.1D, IEEE 802.1Q
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet interface type	Fast Ethernet
USB version	2.0
USB ports quantity	2
Combo SFP ports quantity	1
Ethernet LAN (RJ-45) ports	4
Output voltage	12 - 48 V
Power source type	DC
Power consumption (typical)	9.8 W
Operating altitude	-152.4 - 1524 m
Operating temperature (T-T)	-40 - 60 °C
Operating relative humidity (H-H)	10 - 95 %
Safety	UL 60950-1, 2nd edition; CAN/CSA C22.2 No. 60950-1, 2nd edition, EN 60950-1, 2nd edition; CB to IEC 60950-1, 2nd edition
Flash memory	8000 MB
Storage media	Flash
Internal memory	4096 MB
Internal memory type	DRAM
Electromagnetic compatibility	47 CFR Part 15 B, EN 55032:2015, CISPR 32 Edition 2, CNS13438: 2006, EN 300 386 V1.6.1, ICES-003 Issue 6: 2016, KN 32: 2015, TCVN 7189: 2009, V-2/2015.04, V-3/2015.04, AS/NZ CISPR32, EN 61000-4-2, 3, 4, 5, 6, 8, 9, 16, 17, 18, and 29, CISPR24: 2010 + A1: 2015, EN 300 386 V1.6.1, EN 55024: 2010 + A1: 2015, EN 55035:2017, KN35: 2015, TCVN 7317:2003, QCVN 18:2014
Product color	Black
Routing protocols	BGP, EIGRP, HSRP, RIP-1, RIP-2
Data link protocols	IPv4, IPv6
Supported protocols	SCADA, DNP3, T101-104, Raw Socket TCP, UDP
Mobile network generation	Not supported
VPN support	Cisco Easy VPN Solution client and server NAT transparency Dynamic Multipoint VPN (DMVPN) Tunnel-less Group Encrypted Transport VPN Flex VPN
Firewall security	Cisco IOS
Security algorithms	256-bit AES, HTTPS, IPSec, SSL/TLS
Authentication method	Secure HTTP (HTTPS), FTP, Telnet Authentication Proxy
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	124.9 mm
Width	132.5 mm
Height	60 mm
Weight	1020 g
