Cisco IR1101 Hardware Installation Guide

Antenna Frequency Band Support and
Gain
RF ConnectorsPart Number/ Description
698-960 MHz 8.0-10.0 dBi
1710-2170 MHz 6.0-8.5 dBi
2200-2400 MHz 6.5-9.5 dBi
2500-2700 MHz 8.5-9.5 dBi
Antenna is not designed to operate in
1448-1511 MHz Japan band. Does not
have high gain.
Dual type N
female direct
connector
Cisco Multiband Panel Outdoor 4G MIMO
Antenna (ANT-4G-PNL-OUT-N).
Multiband Panel Outdoor 4G MIMO dual-port
antenna designed to cover cellular 4G bands.
2 dBi, 698-960 MHz
2.8 dBi, 1447-1511 MHz
3.7 dBi, 1710-2690 MHz
1 x SMA(m)Cisco 4G/LTEA, 4G/LTE, and 3G
Omnidirectional Dipole Antenna
(LTE-ANTM-SMA-D).
LTE-ANTM-SMA-D is a high performance
indoor antenna for use in the 698-960, 1448-1511
and 1710-2690 MHz frequency bands.
LTE-ANTM-SMA-D antennas have high
standalone efficiency, and maintain high
efficiency when directly installed on front plate
of a small or medium size Cisco router. However,
depending on chassis size and a variety of other
electromagnetic considerations, installing the
antenna directly on the chassis is not always
recommended.
GPS/GNSS Antennas
Antenna Frequency Band
Support and Gain
RF ConnectorsPart Number / Description
Active GPS antenna, 4.0 dBi
min at Zenith, 1575.42 MHz,
plus 25 dB amplifier gain
Right-angle
TNC(m)
Cisco GPS Antenna (ANT-GPS-OUT-TNC).
Active GPS antenna, integrated 15' LMR-100 cable with
RA-TNC(m).
The ANT-GPS-OUT-TNC integrated GPS RF front end
is designed to reject collocated RF interference.
Active GPS antenna, 4 dBi
@Zenith, 1575.42 MHz, plus
27 dB amplifier gain
SMA(m)Cisco Indoor/Outdoor Active GPS Antenna
(GPS-ACT-ANTM-SMA).
Active GPS antenna that can be physically connected to
the Cisco Integrated Services Routers (ISRs) and Cisco
Enhanced High-Speed WAN Interface Cards (EHWICs)
to receive GPS broadcasts from satellites.
GPS-ACT-ANTM-SMA has GPS filters, but all the filters
are after the LNA. Therefore, antenna may not be suitable
for co-location with strong RF transmitters.
IR1101 Industrial Integrated Services Router Hardware Installation Guide
46
Antenna Selection and Installation
GPS/GNSS Antennas

Cisco IR1101 Specifications

General

DSL WAN	No
Ethernet WAN	Yes
SIM card slot	-
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.1D, IEEE 802.1Q
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet interface type	Fast Ethernet
USB version	2.0
USB ports quantity	2
Combo SFP ports quantity	1
Ethernet LAN (RJ-45) ports	4
Output voltage	12 - 48 V
Power source type	DC
Power consumption (typical)	9.8 W
Operating altitude	-152.4 - 1524 m
Operating temperature (T-T)	-40 - 60 °C
Operating relative humidity (H-H)	10 - 95 %
Safety	UL 60950-1, 2nd edition; CAN/CSA C22.2 No. 60950-1, 2nd edition, EN 60950-1, 2nd edition; CB to IEC 60950-1, 2nd edition
Flash memory	8000 MB
Storage media	Flash
Internal memory	4096 MB
Internal memory type	DRAM
Electromagnetic compatibility	47 CFR Part 15 B, EN 55032:2015, CISPR 32 Edition 2, CNS13438: 2006, EN 300 386 V1.6.1, ICES-003 Issue 6: 2016, KN 32: 2015, TCVN 7189: 2009, V-2/2015.04, V-3/2015.04, AS/NZ CISPR32, EN 61000-4-2, 3, 4, 5, 6, 8, 9, 16, 17, 18, and 29, CISPR24: 2010 + A1: 2015, EN 300 386 V1.6.1, EN 55024: 2010 + A1: 2015, EN 55035:2017, KN35: 2015, TCVN 7317:2003, QCVN 18:2014
Product color	Black
Routing protocols	BGP, EIGRP, HSRP, RIP-1, RIP-2
Data link protocols	IPv4, IPv6
Supported protocols	SCADA, DNP3, T101-104, Raw Socket TCP, UDP
Mobile network generation	Not supported
VPN support	Cisco Easy VPN Solution client and server NAT transparency Dynamic Multipoint VPN (DMVPN) Tunnel-less Group Encrypted Transport VPN Flex VPN
Firewall security	Cisco IOS
Security algorithms	256-bit AES, HTTPS, IPSec, SSL/TLS
Authentication method	Secure HTTP (HTTPS), FTP, Telnet Authentication Proxy
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	124.9 mm
Width	132.5 mm
Height	60 mm
Weight	1020 g
