Cisco IR1101 - Supported RF Cables for the IR1101

Antenna Frequency Band
Support and Gain
RF ConnectorsPart Number / Description
2.5 dBi typical 698-960 MHz
2.5 dBi typical 1710-2700 MHz
One port with GPS element.
2 x 4G/LTE,
SMA(m)
1 x GPS
SMA(m)
Cisco Dual LTE-Single GPS Multi-band Antenna
(4G-LTE-ANTM-O-3-B).
Integrated indoor and outdoor Antenna with three ports;
two ports for 2G, 3G, 4G/LTE and one port for GPS.
The 4G-LTE-ANTM-O-3-B integrated GPS RF front end
is designed to reject collocated RF interference.
Supported RF Cables for the IR1101
The following tables provide information for the cables supported by the IR1101:
• Table 13: N(m) to N(m) RF cables, on page 47
• Table 14: N(m) to TNC(m) RF cable, on page 48
• Table 15: TNC(m) to TNC(f) RF cable, on page 48
• Table 16: TNC(m) to SMA(m) RF cables, on page 48
Table 13: N(m) to N(m) RF cables
RF LossDescriptionAntenna Cable Type
0.2 dB @ 0.7 GHz0.3 dB @ 1.0 GHz0.4 dB @ 1.7
GHz0.5 dB @ 2.4 GHz0.8 dB @ 5.8 GHz
N(m)-STR to N(m)-RALMR-240, 2 foot RF
cableType: Indoor Interconnect.Not DB, CMR or CMP
(not direct burial or flame rated)
AIR-CAB002L240-N
0.2 dB @ 0.7 GHz0.3 dB @ 1.0 GHz0.4 dB @ 1.7
GHz0.5 dB @ 2.4 GHz0.8 dB @ 5.8 GHz
N(m)-STR to N(m)-RALMR-400, 5 foot RF
cableType: outdoor DB (direct burial)
AIR-CAB005LL-N
0.2 dB @ 0.7 GHz 0.3 dB @ 1.0 GHz 0.4 dB @ 1.7
GHz 0.5 dB @ 2.4 GHz 0.8 dB @ 5.8 GHz
N(m)-STR to N(m)-RALMR-400, 5 foot RF
cableType: outdoor DB (direct burial)
CAB-L400-5-N-N
0.2 dB @ 0.7 GHz0.3 dB @ 1.0 GHz0.4 dB @ 1.7
GHz0.5 dB @ 2.4 GHz0.8 dB @ 5.8 GHz
N(m)-STR to N(m)-STR LMR-400, 5 foot RF cable
Type: outdoor DB (direct burial)
CAB-L400-5-N-NS
0.4 dB @ 0.7 GHz 0.5 dB @ 1.0 GHz 0.7 dB @ 1.7
GHz 0.9 dB @ 2.4 GHz 1.5 dB @ 5.8 GHz
N(m)-STR to N(m)-RALMR-400, 10 foot RF cable
Type: outdoor DB (direct burial)
AIR-CAB010LL-N
0.8 dB @ 0.7 GHz 1.0 dB @ 1.0 GHz 1.3 dB @ 1.7
GHz 1.6 dB @ 2.4 GHz2.5 dB @ 5.8 GHz
N(m)-STR to N(m)-RALMR-400, 20 foot RF cable
Type: outdoor DB (direct burial)
CAB-L400-20-N-N
1.0 dB @ 0.7 GHz 1.2 dB @ 1.0 GHz 1.6 dB @ 1.7
GHz 2.0 dB @ 2.4 GHz 3.1 dB @ 5.8 GHz
N(m)-STR to N(m)-STRLMR-400, 25 foot RF cable
Type: outdoor DB (direct burial) with additional
resistance to petrochemicals and oils
AIR-CAB025HZ-N
0.8 dB @ 0.7 GHz 0.9 dB @ 1.0 GHz 1.3 dB @ 1.7
GHz 1.6 dB @ 2.4 GHz 2.6 dB @ 5.8 GHz
N(m)-STR to N(m)-RALMR-600, 30 foot RF cable
Type: outdoor DB (direct burial)
CAB-L600-30-N-N
IR1101 Industrial Integrated Services Router Hardware Installation Guide
47
Antenna Selection and Installation
Supported RF Cables for the IR1101
