Table 14: N(m) to TNC(m) RF cable
RF LossDescriptionAntenna Cable Type
0.8 dB @ 0.7 GHz 1.0 dB @ 1.0 GHz 1.3 dB @
1.7 GHz 1.6 dB @ 2.4 GHz
TNC(m)-RA to N(m)-STRLMR-400, 20 foot RF cable
Type: outdoor DB (direct burial)
CAB-L400-20-TNC-N
1.9 dB @ 0.7 GHz 2.3 dB @ 1.0 GHz 3.1 dB @
1.7 GHz 3.8 dB @ 2.4 GHz
TNC(m)-RA to N(m)-STRLMR-400, 50 foot RF cable
Type: outdoor DB (direct burial)
CAB-L400-50-TNC-N
Table 15: TNC(m) to TNC(f) RF cable
RF LossDescriptionAntenna Cable Type
0.4 dB @ 0.7 GHz 0.5 dB @ 1.0 GHz 0.7
dB @ 1.7 GHz 0.8 dB @ 2.4 GHz
TNC(m)-RA to TNC(f)-STRLMR-400, 10 foot RF cable Type:
outdoor DB (direct burial)
4G-CAB-LMR400-10
0.8 dB @ 0.7 GHz 1.0 dB @ 1.0 GHz 1.3
dB @ 1.7 GHz 1.6 dB @ 2.4 GHz
TNC(m)-RA to TNC(f)-STRLMR-400, 20 foot RF cable Type:
Plenum
4G-CAB-ULL-20
1.9 dB @ 0.7 GHz 2.3 dB @ 1.0 GHz 3.0
dB @ 1.7 GHz 3.6 dB @ 2.4 GHz
TNC(m)-RA to TNC(f)-STRLMR-240, 25 foot RF cable Type:
Plenum
4G-CAB-LMR240-25
3.7 dB @ 0.7 GHz 4.5 dB @ 1.0 GHz 5.9
dB @ 1.7 GHz 7.2 dB @ 2.4 GHz
TNC(m)-RA to TNC(f)-STRLMR-240, 50 foot RF cable Type:
PlenumNote: The cable is not recommended for longer distance
links due to high loss of 50 foot LMR240 at most cellular
frequencies. The customer may need to do a site survey to
validate whether the cable allows sufficient signal-to-noise ratio
to or from cell tower.
4G-CAB-LMR240-50
1.9 dB @ 0.7 GHz 2.3 dB @ 1.0 GHz 3.1
dB @ 1.7 GHz 3.8 dB @ 2.4 GHz
TNC(m)-RA to TNC(f)-STRLMR-400, 50 foot RF cable
Type: Plenum
4G-CAB-ULL-50
5.5 dB @ 0.7 GHz 6.7 dB @ 1.0 GHz 8.8
dB @ 1.7 GHz 10.7 dB @ 2.4 GHz
TNC(m)-RA to TNC(f)-STRLMR-240, 75 foot RF cable Type:
PlenumNote: The cable is not recommended for high throughput
or longer distance links due to high loss of 75 foot LMR240 at
most cellular frequencies. The customer may need to do a site
survey to validate whether the cable allows sufficient
signal-to-noise ratio to or from cell tower.
4G-CAB-LMR240-75
Table 16: TNC(m) to SMA(m) RF cables
RF LossDescriptionAntenna Cable Type
0.8 dB @ 0.7 GHz0.9 dB @ 1.0 GHz1.2 dB @ 1.7
GHz1.5 dB @ 2.4 GHz1.6 dB @ 2.7 GHz
SMA(m)-STR to TNC(m)-STRLMR-240, 10ft RF
cableType: outdoor DB (direct burial)
CAB-L240-10-SM-TM
1.1 dB @ 0.7 GHz1.4 dB @ 1.0 GHz1.8 dB @ 1.7
GHz2.2 dB @ 2.4 GHz2.3 dB @ 2.7 GHz
SMA(m)-STR to TNC(m)-STRLMR-240, 15ft RF
cableType: outdoor DB (direct burial)
CAB-L240-15-SM-TM
1.5 dB @ 0.7 GHz1.8 dB @ 1.0 GHz2.4 dB @ 1.7
GHz2.9 dB @ 2.4 GHz3.1 dB @ 2.7 GHz
SMA(m)-STR to TNC(m)-STRLMR-240, 20ft RF
cableType: outdoor DB (direct burial)
CAB-L240-20-SM-TM
IR1101 Industrial Integrated Services Router Hardware Installation Guide
48
Antenna Selection and Installation
Supported RF Cables for the IR1101
