Cellular Antenna Extension Bases
The following table provide information for the Extension Bases supported by the IR1101.
Table 17: Extension Bases
RF LossDescriptionExtension Base PID
1.1 dB @ 0.7 GHz 1.4 dB @ 1.0 GHz 1.8 dB @ 1.7
GHz 2.1 dB @ 2.4 GHz2.3 dB @ 2.7 GHz
TNC(m)-STR to TNC(f)-STRLMR-195, 10 foot RF
cable Type: PlenumAntenna extension bases
4G-AE010-R
1.7 dB @ 0.7 GHz 2.0 dB @ 1.0 GHz 2.6 dB @ 1.7
GHz 3.2 dB @ 2.4 GHz3.4 dB @ 2.7 GHz
TNC(m)-STR to TNC(f)-STRLMR-195, 15 foot RF
cable Type: Plenum Antenna extension bases
4G-AE015-R
0.2 dB @ 0.7 GHz0.2 dB @ 1.0 GHz0.3 dB @ 1.7
GHz0.3 dB @ 2.4 GHz0.3 dB @ 2.7 GHz
TNC(f)-STR to SMA(f)-STR LMR-195, 1ft RF
cableType: Plenum Antenna extension bases
LTE-AE-MAG-SMA
Accessories
The following table provides information for other accessories supported by the IR1101:
• Table 18: Cisco Lightning Arrestors, on page 49
• Table 19: Cisco Coaxial Adapters, on page 49
Table 18: Cisco Lightning Arrestors
Arrestor Type and Frequency Range (MHz)Connectors TypeCisco PID
DC to 6000 MHz GDT typeSupports active GNSS antennas, passes DCN(m)-STR to N(f)-STRCGR-LA-NM-NF
698 to 2700 MHzHigh power, ultra low shunt impedance, HPF typeDoes not
pass DC, no support for active GNSS antennas
N(m)-STR to N(f)-STRACC-LA-H-NM-NF
DC to 6000 MHzGDT typeSupports active GNSS antennas, passes DCN(f)-STR to N(f)-STRCGR-LA-NF-NF
DC to 6000 MHzGDT typeSupports active GNSS antennas, passes DCTNC(f)-STR to TNC(m)-STRACC-LA-G-TM-TF
DC to 6000 MHzGDT typeSupports active GNSS antennas, passes DCTNC(f)-STR to TNC(f)-STRACC-LA-G-TF-TF
Table 19: Cisco Coaxial Adapters
Connectors TypeCisco PID
N(f)-STR to N(f)-STRAIR-ACC370-NF-NF
SMA(m)-STR to TNC(f)-STRLTE-ADPT-SM-TF
IR1101 Industrial Integrated Services Router Hardware Installation Guide
49
Antenna Selection and Installation
Cellular Antenna Extension Bases
