Figure 27: Mounting the Expansion Module
Step 3 Tighten the screws to a torque of 13-15 in. lbs (1.5-1.7) newton meter). When complete, the two devices form a single
assembly as shown in Figure 28: Completed Assembly, on page 54.
IR1101 Industrial Integrated Services Router Hardware Installation Guide
53
Installing the IRM-1100 Expansion Module
Installing the Expansion Module
