A-19
Cisco Nexus 7000 Series Hardware Installation and Reference Guide
OL-23069-06
Appendix A Technical Specifications
Chassis Airflow
Table A-15 Airflow for a Fully Configured Cisco Nexus 7009 Switch
Temperature
System Airflow
(cfm)
Fabric Airflow
(cfm)
Total Airflow
(cfm)
<55ºF (13ºC) 686 76 762
55 to 62ºF (13 to 17ºC) 686 92 778
64 to 71ºF (18 to 22ºC) 686 107 793
73 to 80ºF (23 to 27ºC) 686 123 809
82 to 89ºF (28 to 32ºC) 686 143 829
91 to 98ºF (33 to 37ºC) 768 153 921
100 to 107ºF (38 to 42ºC) 842 173 1015
109 to 116ºF (43 to 47ºC) 1044 189 1233
118 to 125ºF (48 to 52ºC) 1203 203 1406
127 to 136ºF (53 to 58ºC) 1326 221 1547
>136ºF (>58ºC) 1203 250 1576
Table A-16 Airflow for a Fully Configured Cisco Nexus 7010 Switch
Temperature
System Airflow
(cfm)
Fabric Airflow
(cfm)
Total Airflow
(cfm)
<55ºF (13ºC) 406 37 443
55 to 62ºF (13 to 17ºC) 493 44 537
64 to 71ºF (18 to 22ºC) 534 50 584
73 to 80ºF (23 to 27ºC) 576 56 632
82 to 89ºF (28 to 32ºC) 659 63 722
91 to 98ºF (33 to 37ºC) 744 70 814
100 to 107ºF (38 to 42ºC) 853 75 928
109 to 116ºF (43 to 47ºC) 1044 100 1144
118 to 125ºF (48 to 52ºC) 1242 154 1396
127 to 136ºF (53 to 58ºC) 1447 162 1609
>136ºF (>58ºC) 1447 162 1609
Table A-17 Airflow for a Fully Configured Cisco Nexus 7018 Switch
Temperature
System Airflow
(cfm)
Fabric Airflow
(cfm)
Total Airflow
(cfm)
<55ºF (13ºC) 1459 71 1530
55 to 62ºF (13 to 17ºC) 1459 83 1542
