Appendix B Transceivers and Module Connectors
1-Gigabit SFP Transceivers
This section includes the following topics:
• 1000BASE-T and 1000BASE-X SFP Transceivers, page B-10
• 1000BASE-CWDM SFP Transceiver Cables, page B-13
• 1000BASE-DWDM SFP Transceivers, page B-14
1000BASE-T and 1000BASE-X SFP Transceivers
The 1000BASE-T and 1000BASE-X SFPs are hot-swappable transceivers that you plug into
SFP-compatible I/O modules. The 1000BASE-T transceiver, shown in Figure B-4, provides an RJ-45
connection for copper cables, and the 1000BASE-X transceiver, shown in Figure B-5, provides an
optical connection for fiber-optic cables.
Table B-9 SFP Transceivers Used with Each I/O Module
Transceiver
I/O Modules
48-port 1-Gigabit
(N7K-M148GS-11)
48-port 1-Gigabit
with XL option
(N7K-M148GS-11L)
48-port
1- and 10-Gigabit
(N7K-F248XP-25)
32-port
1- and 10-Gigabit
(N7K-F132XP-15)
CWDM-SFP-xxxx X X X X
DWDM-SFP-xxxx X X X X
GLC-BX-D X X X
GLC-BX-U X X X
GLC-LH-SM X X X X
GLC-LH-SMD X X X X
GLC-SX-MM X X X X
GLC-SX-MMD X X X X
GLC-T X X X X
GLC-ZX-SM X X X X
SFP-GE-L X X X X
SFP-GE-S X X X X
SFP-GE-T X X X X
SFP-GE-Z X X X X
