5-24
Cisco Nexus 7000 Series Hardware Installation and Reference Guide
OL-23069-07
Chapter 5 Installing a Cisco Nexus 7018 Chassis
Installing the Front Door and Air Intake Frame
Figure 5-15 Positioning the Hinge Bracket to the Cable Management Frame and Chassis
Step 4
Attach the bracket to the chassis with eight loosely fastened M4x8 screws, as shown in Figure 5-16.
1 Alignment pins 2 Alignment holes
