6-12
Cisco Nexus 7000 Series Hardware Installation and Reference Guide
OL-23069-07
Chapter 6 Installing Power Supplies
Connecting a DC Power Supply to DC Power Sources
Figure 6-4 Connecting DC Power Supplies to the Grid for Power Supply [N+1] Redundancy
+
-
+
-
+
-
+
-
+
-
+
-
+
-
+
-
+-+
-
+-+
-
+-+
-
+-+
-
-+
-+
5
6
5
6
1
1
1
3
4
4
4
3
2 2
334719
1 3-kW DC power supply 4 6-kW DC power supply
2 DC power grid 5 Connection for available power (for a minimum of 3 kW)
3 Redundant power supply 6 Power supply redundancy connection (power connection at least equals the
power connection for any power supply providing available power)
