Configuring Networking
Configuring a Mobile Network
Cisco RV130/RV130W Wireless Multifunction VPN Router Administration Guide 26
3
STEP 3 Verify that the Card Status field shows your mobile card is Connected.
Configuring Mobile Network Settings Manually
To change mobile network parameters in the Mobile Network Setup area, click
the Manual radio button. The device automatically detects supported modems
and lists the appropriate configuration parameters. To override global parameters,
select Manual.
STEP 1 Enter information in the following fields:
Field Description
Access point Name
(APN)
Internet network that the mobile device is connecting to.
Enter the access point name provided by your mobile
network service provider. If you do not know the name
of the access point, contact your service provider.
Dial Number Dial number provided by your mobile network service
provider for the Internet connection.
Username
Password
User name and password provided by your mobile
network service provider.
SIM Check SIM card check enable or disable.
SIM PIN PIN code associated with your SIM card. This field is
only displayed for GSM SIM cards.
You can modify the SIM PIN in either Auto or Manual
mode.
Server Name Name of the server for the Internet connection (if
provided by your service provider).
Authentication Authentication used by your service provider. The value
can be changed by choosing the authentication type
from the drop-down list. The default is Auto. If you do
not know which type of authentication to use, select
Auto.
