Cisco RV130W Administration Guide

Configuring the Firewall
Configuring One-to-One Network Address Translation (NAT)
Cisco RV130/130W Wireless Multifunction VPN Router Administration Guide 94
5
Configuring One-to-One Network Address Translation (NAT)
Use the One-to-one NAT page to map local IP addresses behind your firewall to
global IP addresses. One-to-one NAT is a way to make systems configured with
private IP addresses, which are behind a firewall, appear to have public IP
addresses.
To add a One-to-One NAT rule:
STEP 1 Choose Firewall > One-to-One NAT.
STEP 2 Click Add Row.
STEP 3 In the Private Range Begin field, enter the starting IP address in the private (LAN) IP
address range.
STEP 4 In the Public Range Begin field, enter the starting IP address in the public (WAN) IP
address range.
STEP 5 In the Range Length, enter the number of public IP addresses that should be
mapped to private addresses.
STEP 6 In the Service field, choose the service for which the rule applies. Services for
one-to-one NAT allow you to configure the service to be accepted by the private
IP (LAN) address when traffic is sent to the corresponding public IP address.
Configured services on private IP addresses in the range are accepted when
traffic is available on the corresponding public IP address.
STEP 7 Click Save.
Configuring Port Forwarding
Port forwarding is used to redirect traffic from the Internet from one port on the
WAN to another port on the LAN. Common services are available or you can define
a custom service and associated ports to forward.
The Single Port Forwarding Rules and Port Range Forwarding Rules pages list
all the available port forwarding rules for this device and allow you to configure
port forwarding rules.

Cisco RV130W Specifications

General

DSL WAN	-
Ethernet WAN	Yes
SIM card slot	No
Wi-Fi band	Single-band (2.4 GHz)
Wi-Fi standards	Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	1000 Mbit/s
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.1D, IEEE 802.1p, IEEE 802.1w, IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
USB 2.0 ports quantity	1
Supported network protocols	DHCP, PPPoE, PPTP, L2TP, DNS, IGMP, RSTP
Antennas quantity	2
Security algorithms	WEP, WPA, WPA2-PSK
Product type	Tabletop router
Product color	Black
LED indicators	LAN, Power, USB, WAN, WLAN
Output voltage	12 V
Power source type	DC
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 85 %
