Cisco RV130W Administration Guide

Configuring Networking
Configuring IPv6
Cisco RV130/RV130W Wireless Multifunction VPN Router Administration Guide 48
3
Configuring IPv6 LAN Connections
In the IPv6 mode, the LAN DHCP server is enabled by default (similar to the IPv4
mode). The DHCPv6 server assigns IPv6 addresses from configured address
pools that use the IPv6 prefix length assigned to the LAN.
To configure IPv6 LAN settings on your device, you must first set the IP mode to
one of the following modes:
• LAN:IPv6, WAN:IPv4
• LAN:IPv6, WAN:IPv6
• LAN:IPv4+IPv6, WAN:IPv4
• LAN:IPv4+IPv6, WAN:IPv4+IPv6
See Configuring the IP Mode for more information on how to set the IP mode.
To configure IPv6 LAN settings:
STEP 1 Choose Networking > IPv6 > IPv6 LAN Configuration.
STEP 2 Enter the following information to configure the IPv6 LAN address:
STEP 3 Click Save or continue to configure IPv6 DHCP LAN settings.
STEP 4 Enter the following information to configure the DHCPv6 settings:
IPv6 Address Enter the IPv6 address of the device.
The default IPv6 address for the gateway is fec0::1
(or FEC0:0000:0000:0000:0000:0000:0000:0001).
You can change this 128-bit IPv6 address based on
your network requirements.
IPv6 Prefix Length Enter the IPv6 prefix length.
The IPv6 network (subnet) is identified by the initial
bits of the address called the prefix. By default, the
prefix is 64 bits long.
All hosts in the network have the identical initial bits
for their IPv6 address; you set the number of
common initial bits in the network addresses in this
field.

Cisco RV130W Specifications

General

DSL WAN	-
Ethernet WAN	Yes
SIM card slot	No
Wi-Fi band	Single-band (2.4 GHz)
Wi-Fi standards	Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	1000 Mbit/s
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.1D, IEEE 802.1p, IEEE 802.1w, IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
USB 2.0 ports quantity	1
Supported network protocols	DHCP, PPPoE, PPTP, L2TP, DNS, IGMP, RSTP
Antennas quantity	2
Security algorithms	WEP, WPA, WPA2-PSK
Product type	Tabletop router
Product color	Black
LED indicators	LAN, Power, USB, WAN, WLAN
Output voltage	12 V
Power source type	DC
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 85 %
