Cisco RV130W Administration Guide

Configuring Wireless Networks
Configuring WDS
Cisco RV130/RV130W Wireless Multifunction VPN Router Administration Guide 76
4
You can configure WDS in Bridge mode where one AP acts as the common link
between multiple APs or in Repeater mode where one AP connects two APs
without a wired connection to the LAN, by repeating signals using the wireless
connection.
WDS is supported on one SSID only.
To configure WDS in Bridge mode:
STEP 1 Choose Wireless > WDS.
STEP 2 To enable WDS, check the WDS check box.
STEP 3 Select the WDS Bridge radio button.
STEP 4 In the Remote Wireless Bridge’s MAC Address section, enter the MAC addresses
of up to four access points to use as bridges in the MAC 1, MAC 2, MAC 3,and
MAC 4 fields.
STEP 5 Click Save.
To configure WDS in Repeater mode:
STEP 1 Choose Wireless > WDS.
STEP 2 Check the WDS check box.
STEP 3 Choose the repeater mode. If you select Allow wireless signal to be repeated by
a repeater, enter the MAC addresses of up to three access points to use as
repeaters in the MAC 1, MAC 2, and MAC 3 fields.
STEP 4 If you select Repeat wireless signal of a remote access point:
• Enter the MAC address of a wireless access point in the MAC field.
• Click Show Available Networks to display the Available Networks Table.
Click Connect to add the MAC address of the selected access point to the
MAC field.
STEP 5 Click Save.

Cisco RV130W Specifications

General

DSL WAN	-
Ethernet WAN	Yes
SIM card slot	No
Wi-Fi band	Single-band (2.4 GHz)
Wi-Fi standards	Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	1000 Mbit/s
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.1D, IEEE 802.1p, IEEE 802.1w, IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
USB 2.0 ports quantity	1
Supported network protocols	DHCP, PPPoE, PPTP, L2TP, DNS, IGMP, RSTP
Antennas quantity	2
Security algorithms	WEP, WPA, WPA2-PSK
Product type	Tabletop router
Product color	Black
LED indicators	LAN, Power, USB, WAN, WLAN
Output voltage	12 V
Power source type	DC
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 85 %
