Cisco RV180 Administrator's Manual

Configuring the Firewall
Firewall Configuration Examples
Cisco RV180/RV180W Administration Guide 101
4
Example 3: Multi-NAT Configuration
In this example, you want to configure multi-NAT to support multiple public IP
addresses on one WAN port interface.
Create an inbound rule that configures the firewall to host an additional public IP
address. Associate this address with a web server on the DMZ. If you arrange with
your ISP to have more than one public IP address for your use, you can use the
additional public IP addresses to map to servers on your LAN. One of these public
IP addresses is used as the primary IP address of the router. This address is used
to provide Internet access to your LAN PCs through NAT. The other addresses are
available to map to your DMZ servers.
The following addressing scheme is used to illustrate this procedure:
• WAN IP address: 10.1.0.118
• LAN IP address: 192.168.1.1; subnet 255.255.255.0
• Web server PC in the DMZ, IP address: 192.168.1.2
• Access to Web server: (simulated) public IP address 10.1.0.52
Finish 134.177.88.254
Send to Local Server (DNAT IP) 192.168.1.11
Rule Status Enabled
Parameter Value
Parameter Value
Connection Type Inbound
Action Always Allow
Service HTTP
Source IP Single Address
Start 10.1.0.52
Send to Local Server (DNAT IP) 192.168.1.2 (local IP address of your web server)
Rule Status Enabled

Cisco RV180 Specifications

General

WAN Ports	1
LAN Ports	4
VPN Support	Yes
Wireless Support	No
Firewall	Yes
Device Type	VPN Router
VPN Tunnels	10
Authentication	MD5, SHA1
Power Supply	12V DC, 1A
Encryption	3DES, AES
VPN Protocols	IPSec
Operating Temperature	0 to 40 °C
Storage Temperature	-20 to 70 °C
Humidity	10% to 85% non-condensing
Dimensions	130 x 130 x 35 mm
Weight	0.28 kg
