Cisco RV180 Administrator's Manual

Introduction
Mounting the Cisco RV180/RV180W
Cisco RV180/RV180W Administration Guide 9
1
To mount the firewall to the wall:
STEP 1 Determine where you want to mount the firewall. Verify that the surface is smooth,
flat, dry, and sturdy.
STEP 2 Drill two pilot holes into the surface 2-7/16 inches (61 mm) apart, and with a
minimum of 5.12 inches (130 mm) of clearance.
STEP 3 Insert a screw into each hole, leaving a gap between the surface and the base of
the screw head of at least 0.1 inches (3 mm).
284157
2-7/16" (61 mm)

Cisco RV180 Specifications

General

WAN Ports	1
LAN Ports	4
VPN Support	Yes
Wireless Support	No
Firewall	Yes
Device Type	VPN Router
VPN Tunnels	10
Authentication	MD5, SHA1
Power Supply	12V DC, 1A
Encryption	3DES, AES
VPN Protocols	IPSec
Operating Temperature	0 to 40 °C
Storage Temperature	-20 to 70 °C
Humidity	10% to 85% non-condensing
Dimensions	130 x 130 x 35 mm
Weight	0.28 kg
