Cisco UCS B200 M5 User Manual

Procedure
Step 1
Loosen the captive screws on the front of the blade.
Step 2
Remove the blade from the chassis by pulling the ejector lever on the blade until it unseats the blade server.
Step 3
Slide the blade part of the way out of the chassis, and place your other hand under the blade to support its
weight.
Step 4
Once removed, place the blade on an antistatic mat or antistatic foam if you are not immediately reinstalling
it into another slot.
Step 5
If the slot is to remain empty, install a blank faceplate (N20-CBLKB1) to maintain proper thermal temperature
and keep dust out of the chassis.
Server Troubleshooting
For general troubleshooting information, see the Cisco UCS Manager Troubleshooting Reference Guide.
Cisco UCS B200 M5 Blade Server Installation and Service Note
10
Installing a Blade Server
Server Troubleshooting

Cisco UCS B200 M5 Specifications

General

Form Factor	Blade
Processor	Intel Xeon Scalable Processors
Management	Cisco UCS Manager
Processor Sockets	2
Product Type	Blade Server
Memory	Up to 3 TB DDR4
Memory Slots	24 DIMM slots
Storage	Up to 2 x SAS/SATA drives
Expansion Slots	Mezzanine card
RAID Support	RAID 0, 1
Network	10 Gigabit Ethernet, 25 Gigabit Ethernet
Power Supply	Part of UCS Blade Server Chassis
