Page #61 background imageLoading...
Page #61 background image
CHAPTER 4
Technical Specifications
This chapter contains the following sections:
Physical Specifications for the Cisco UCS B200 M5 Blade Server, page 51
Physical Specifications for the Cisco UCS B200 M5 Blade Server
ValueSpecification
1.95 inches (50 mm)Height
8.00 inches (203 mm)Width
24.4 inches (620 mm)Depth
Base server weight = 9.51 lbs (4.31 kg) (no HDDs, no CPUs, no DIMMs, no
mezzanine adapters or memory)
Minimally configured server = 11.29 lbs (5.12 kg) (no HDDs, 1 CPU, 8 DIMMs,
VIC 1340 but no additional mezzanine adapter)
Fully configured server = 16 lbs (7.25 kg) (2 HDDs, 2 CPUs, 24 DIMMs, VIC
1340 and additional mezzanine adapter both populated)
Weight
Cisco UCS B200 M5 Blade Server Installation and Service Note
51

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Cisco UCS B200 M5 and is the answer not in the manual?

Cisco UCS B200 M5 Specifications

General IconGeneral
Form FactorBlade
ProcessorIntel Xeon Scalable Processors
ManagementCisco UCS Manager
Processor Sockets2
Product TypeBlade Server
MemoryUp to 3 TB DDR4
Memory Slots24 DIMM slots
StorageUp to 2 x SAS/SATA drives
Expansion SlotsMezzanine card
RAID SupportRAID 0, 1
Network10 Gigabit Ethernet, 25 Gigabit Ethernet
Power SupplyPart of UCS Blade Server Chassis
