- 164 -
2.2.13 Commands for Non-volatile Memory
GS ( L pL pH m fn [parameter]
GS 8 L p1 p2 p3 p4 m fn [parameter]
[Function] Specifying graphics data
[Code] <1D>H<28>H<4C>H<pL><pH><m><fn>
<1D>H<38>H<4C>H<p1><p2><p3><p4><m><fn>
* In the explanation of function, the code of GS ( L is used.
• GS ( L and GS 8 L ) are the same function.
• When [parameter] exceeds 65533 bytes in each function, GS 8 L is used.
[Outline] [The specification which is common to the model]
• Executes the processing related to the graphics data specified by the function code (fn).
[The specification which depend on the model]
CT-S2000/CT-S4000/CT-S801/CT-S851/CT-S601/CT-S651/CT-S310II/CT-D150/CT-E351
fn
Code
Function No.
Function
0, 48 GS ( L pL pH m fn Function48
Sends NV graphics memory
capacity.
2, 50 GS ( L pL pH m fn Function50
Prints graphics data stored in print
buffer.
3, 51 GS ( L pL pH m fn Function51
Sends the remaining amount of NV
graphics memory.
64 GS ( L pL pH m fn d1 d2 Function64
Sends key code list of defined NV
graphics.
65 GS ( L pL pH m fn d1 d2 d3 Function65
Erases all data of NV graphics in a
lump.
66 GS ( L pL pH m fn kc1 kc2 Function66
Erases the specified NV graphics
data.
67
GS ( L pL pH m fn a kc1 kc2 b xL xH
yL yH [c d1…dk] 1… [c d1…dk] b
Function67
Defines raster graphics data to NV
memory.
69
GS ( L pL pH m fn kc1 kc2 x y
Function69
Prints the specified NV graphics.
112
GS ( L pL pH m fn a bx by c xL xH yL
yH d1…dk
Function 112
Stores raster graphics data to print
buffer.
