4.2.7 MSW7
●MSW7-1: Baud rate
[Outline] Selects the baud rate which is serial interface communication condition.
Enabled if DSW1-1 OFF is set [following memory switch setting] .
Setting Value
Baud Rate
1200bps,2400bps,4800bps,9600bps,19200bps,
38400bps,57600bps,115200bps
●MSW7-2: Data length
[Outline] Selects the data length, which is a serial interface communication condition.
Enabled if DSW1-1 OFF is set [following memory switch setting] .
Setting Value
Data Length
7bits,8bits
●MSW7-3: Stop bit
[Outline] Selects the stop bit, which is a serial interface communication condition.
Enabled if DSW1-1 OFF is set [following memory switch setting] .
Setting Value
Stop Bit
1bit,2bits
●MSW7-4: Parity
[Outline] Selects the parity, which is a serial interface communication condition.
Enabled if DSW1-1 OFF is set [following memory switch setting] .
Setting Value
Parity
NONE, ODD, EVEN
●MSW7-5: Flow control
[Outline] Selects the flow control, which is a serial interface communication condition.
Enabled if DSW1-1 OFF is set [following memory switch setting] .
Setting Value
Flow Control
DTR/DSR, XON/XOFF
